CITF Turtle Back Single Bag Filter
Bag Filter

CITF Turtle Back Single Bag Filter

The CITF turtle back single bag filter adopts a clever structural design, allowing liquid to enter from the side and flow directly into the filter bag through the reverse flow of the turtle back. The top cover of the turtle back is cast in one piece, which can provide a good sealing effect and achieve a certain degree of pressure resistance.
Advantage:
1. Good sealing: there will be no external leakage problems, and there will also be no side leakage problems;
2. Low pressure loss;
3. Simple and convenient operation.

Advantage

Model Description

Technical Parameter Table

Filter model

CJBT-0101-BB10

CJBT-0102-BB10

CJBT-0104-BB10

Filter bag specifications

Size 01

Size 02

Size 04

Filtration area

0.25㎡

0.5㎡

0.14㎡

Standard flow rate m³/h

20

36

11

Design pressure bar

10

10

10

Design temperature °C

160

160

160

Material

SS304, SS361, 2205, HC22, PP, PTFE lining

Sealing ring material

Nitrile rubber, EPDM, fluorine rubber, tetra fluoro fluorine

Surface treatment

Shot peening, pickling passivation, polishing, wire drawing

Volume (L)

13

27

5

Weight (Kg)

29

33

16
